Technical Parameters Operating voltage DC12V-24V Waterproof Working current less than 6A Working power less than 25W Flashing frequency 60-100 times/min Size 600MM×260MM×50MM Weight (single piece) 2.6kg Whole carton weight 5.6KG
Features Adopting imported ultra-high brightness LED light, the brightness is bigger than 12000mcd, with small working current, stable performance and long span life; The outer case is made of PC material for integral injection molding, with good anti-aging and anti-seismic performance;
The lens adopts PC material injection molding,with high mechanical strength, wear resistance, no discoloration; The circuit board adopts double-layer technology, with high temperature resistance; The bracket is made of cold rolled iron steel, with high temperature painting, rust-free, and the screw is made of stainless steel;
Flash controller adopts imported switch tube, stable and reliable; Luminous pixels consist of 5pcs of F5 lamp beads, 14MIL large-size chips, and the power supply is independent. Glowing pixel is equipped with electroplating reflector cup, which increase the effective distance of flashing greatly; Arrow lights is one new type vehicle-mounted traffic lights.
Its appearance is exquisite and beautiful, the operation is simple and the installation is easy. The greatest advantage is that the overall weight is light, the power consumption is low, and the service life is long, and the viewing distance is long. The arrow light is widely used, such as engineering rescue vehicles, sprinklers, road construction vehicles, road maintenance vehicles, road sweepers and road warning signs etc.
